Q550G6 Cheap 1U Rack Server Core i5 6200u 6 * 1000M LAN ethernet Firewall Security Appliance Router Network 1U Rack Server 4G RAM 32G SSD

Product Description

CPU onboard,You can choose what CPU you want.

Q515G6 Intel Celeron Processor 3865U 2M Cache, 1.80 GHz Q525G6 Intel Celeron Processor 3965U 2M Cache, 2.20 GHz Q530G6 Intel Core i3-6100U,2.3GHz,dual core Q535G6 Intel Core i3-7100U Processor,3M Cache, up to 2.40 GHz Q550G6 Intel Core i5-6200U,2.3GHz,to 2.8GHz,dual core Q555G6 Intel Core i5-7200U Processor,3M Cache, up to 3.10 GHz Q570G6 Intel Core i7-6500U,2.5GHz,to 3.1GHz,dual core Q575G6 Intel Core i7-7500U Processor,4M Cache, up to 3.50 GHz

Item nameQ500G6 with 1U Rack.

Dimension：440*112*44MM(L*H*W)

Memory(RAM):DDR4L SO-DIMM Socket (Up 16G,2133MHz)

Storage:1x 2.5 inch HDD/SSD 1X full length Mini-PCIE for Msata

LAN:6 * Intel I211-AT- 10/100/1000 Controller

WiFi :Option 1 : USB WIFI RT3070( by default)

Option 2 : Antheros PCIE WIFI (choose it,there will be 5 LAN works )

(For option 1,pls use it on AP mode Pfsense settings)

Audio Solution:Realtek ALC662 6-Channel HD Audio

Expansion port:1x SIM card slot , 2*RS-485(optional)

Front-Panel:

Connectorspower on/off button

HDD LED, Power LEDs

2 *USB 2.0 Ports

2 * USB 3.0 ports

Serial port: 1RS-232(COM 1)

HD Video port

Rear-Panel Connectors

12V DC input ,(DC Jack 5.5mm,2.5mm)

6* Intel RJ-45 Ports for Gigabit LAN

Operating System

1)Mini PC supports Windows, Linux, pfSense, CentOS, Sophos, OPNsense, VyOS, Linux iptables, Untangle, etc. It will comes with inactive Windows 10 inactive and without any Windows license. If you prefer to install other OS, please leave a message,you also can reinstall OS by yourself.

2)F11 key boot from USB Drive. Delete key enter BIOS.

Packing List

1 x Mini PC

1 x Power supply: adapter and plug (US/ UK/ EU/ AU/ IT standard)

2 x ears

1 x Packaing box

2 x Antennas if order Wi-Fi.(If you choose Wifi option)

Main Port: 1 HD Video +1 RS232+ 2 USB 2.0 + 2 USB 3.0 +6 Intel I211 AT LAN.
CPU:Intel Core i5-6200U,2.3GHz,to 2.8GHz,dual core
Configuration:Q550G6 I5 6200U 1U Case (4G DDR4 RAM, 32G mSATA SSD,No WiFi )
We can provide Windows drivers download link and motherboard user manual download link.
Perfect fit for a LAN or WAN router, firewall, proxy, WiFi access point, DHCP Server, DNS Server, etc.
