J-Tech Digital 4K USB KVM HDMI Extender Over Cat6/6a/7 Ethernet up to 328 FT (1080P), Supports HDMI 1.4 HDCP 1.4, 2 x USB 2.0, Near Zero Latency

Product Description

1 UHD 4K Resolution

2 Long Range Transmission

3 Near Zero Latency

4 Audio Extraction Function

5 Dual USB2.0 KVM Extension

Overview

The J-Tech Digital JTECH-KVE2 HDMI & USB 2.0 KVM extender allows users to extend USB keyboard, mouse and HDMI signals up to 328 feet over CAT6 ethernet cable with near zero latency. This allows users to control a computer (or USB device) remotely up to 300+ feet away. Connect two remote HDMI displays to the receiver’s dual HDMI output ports and one local HDMI display to the transmitter’s local loop HDMI output port for flexible monitoring options. Extract source audio via the 3.5mm analog audio output ports found on both the transmitter and receiver so that users can route audio to a 3rd party audio processor/amplifier.

Need to control multiple sources/computers? Check out the J-Tech Digital JTECH-KV41 4-Port HDMI USB KVM Switch (ASIN: B088WDDQQ2)

Input Ports – (1) TX – 1 x HDMI In | 1 x USB 2.0 Type-B (2) RX – 1 x HDMI | 1 x RJ-45 | 1 x IR In | 2 x USB 2.0 Type-AOutput Ports – (1) TX – 1 x HDMI Out (Pass-thru) | 1 x RJ-45 | 1 x IR Out | 1 x 3.5mm Audio Out (2) RX – 2 x HDMI Out | 1 x 3.5mm Audio OutSupported Resolutions– Up to 4K@30HzTransmission Distance– 328 FT / 100M over CAT6 Solid CopperSupported Audio Formats– PCM, LPCM, Dolby Digital, DTSPower Supply– Input: 100-240VAC, 50/60Hz | Output: 5VDC 2ADimensions– 5.12 in x 3.94 in x 0.87 in

✔ 4K@30HZ UP TO 328 FT – Extend 4K 30Hz & 1080p HDMI signals up to 328 feet / 100 meters away over CAT6 ethernet cable. High resolution 4K image extension with near zero latency (ideal for PC use).
✔ DUAL USB 2.0 (480 Mbps) KVM EXTENSION – 2 x USB ports found on the receiver extend USB 2.0 signals up to 328 feet away over CAT6 ethernet cable. Plug and play installation makes setup a breeze with no need for additional drivers.
✔ DUAL HDMI OUTPUT PORTS ON RECEIVER – Connect two HDMI displays to the receiver’s dual HDMI output ports and a local HDMI display to the transmitter’s local loop HDMI output port for flexible monitoring options.
✔ 3.5MM AUDIO EXTRACTION PORTS – Extract source device audio via the 3.5mm analog audio output ports found on both the transmitter and receiver. Flexible audio routing options mean that you can incorporate 3rd party audio processors with ease.
✔ FREE LIFETIME TECHNICAL SUPPORT – All J-Tech Digital products include a One-Year Manufacturer Replacement Warranty and free lifetime technical support from our customer support team located in Sugar Land, TX. Support is available from 9AM – 6PM CST, Monday through Friday. Contact information available on our seller page.
